Arlingtonâ„¢ LVDR2 Combo Box for Power and Low Voltage, Old Work
Arlington™ LVDR2 Combo Box for Power and Low Voltage, Old Work Need to install power AND low voltage boxes? Try Arlington’s non-metallic combination boxes. The LVDR2 Power and Low Voltage Combo Box is the best way to install power and phone/cable outlets together, in one neat location for existing construction. For Low Voltage and Power Use Dual Voltage Combo Box For Retrofit Applications - Post Construction Mounts to Panels, Sheetrock Etc. Impact Resistant Plastic results in less breakage on Job site Easy Flat Sided Wall Panel Cut-Out - No Weird Cut-Out Built-in Cable Management on Both Sides 1/2inch and 3/4inch Knock-outs on Low Voltage Side 1/2inch Knock-Out and NM Cable Connector on Power Side 17 cu. in Power Side - 3.3inch Deep Clamps to Walls or Panels - 0.30inch to 1.0inch Thick Side Wall Thickness - 0.090inch Flange Thickness - 0.050inch and 0.090inch Panel Cut Out Dimensions - 3.83inch W x 3.60inch H Overall Dimensions - 4.17inch W x 4.25inch H x 3.3inch Depth Installation Why settle for separate and uneven side-by-side boxes when you can have one neat installation? The LVDR2 adjusts to fit walls from 1/4inch to 1-1/2” thick in existing construction. As the mounting screws are tightened, the specially designed wings flip up, locking the box firmly in place. The LVDR2 can be used as its own template for cutting the perfect hole in the wall. The low-voltage side of the LVDR2, for low-voltage/Class 2 wiring includes combo 1/2inch and 3/4” knockouts for easy access to cable raceways. On the power side, a NM cable connector is pre-installed! The LVDR2 protects a cable from damage - and it’s the sturdiest box of its kind. All the strength you need is contained in the lightweight, non-metal construction of the Power and Low Voltage Combo Box. What’s more, the LVDR2 also protects low voltage cable from damage.Arlington™ Arlington™ has been a leading manufacturer of quality electrical products and fittings since its founding in 1949. The company manufactures products that meet or exceed the changing needs of electrical distributors and contractors, with the vast majority produced in America.
