Arlingtonâ„¢ LV1 Single Gang Low Voltage Mounting Bracket, Old Work
Arlington™ LV1 Single Gang Low Voltage Mounting Bracket, Old Work Arlington Industries LV1 Low Voltage Mounting Bracket features shallow mounting depth which allows for more wires to be run in the wall cavities. The shallow mounting depth also works better with reversible wall plates since the box itself is not obstructing the wire passage. Arlington Industries has also designed their retrofit brackets to have a thinner external flange so wall plates sit flatter against the wall. IMPORTANT: For Low Voltage Class 2 Use Only Single Gang Open Back Bracket For Retrofit Applications - Post Construction Run More Wire Easier with Brackets vs Boxes Mounts to Panels, Sheetrock Etc. Impact Resistant Plastic results in less breakage on Job site Easy Flat Sided Wall Panel Cut-Out - No Weird Cut-Out Shallow Mount - Only 0.40inch Deep (Not Including Flag Post) Clamps to Walls or Panels - 0.30inch to 1.0inch Thick Side Wall Thickness - 0.080inch Flange Thickness - 0.050inch Sticks out less from the wall Panel Cut Out Dimensions - 2.15inch W x 3.60inch H Overall Dimensions - 2.5inch W x 4.25inch H x 1.7inch Depth (Includes Flag Post) Installation Recessed, oval-shaped screw holes allow for final shifting and straightening of the device when installed. It even doubles as its own cut-out template! All in all, this bracket installs in less time than steel or plastic mud rings and costs less, too. Install either vertically or horizontally based on the needs of the old-work application. Secure Mount The UL listed LV1 adjusts to fit 1/4” to 1” thick wallboard, paneling, or drywall and holds snug when installing via wings on both top and bottom of the bracket. These specially designed wings flip up for a secure mount when mounting screws (not included) are tightened. The thin lip of the face sits in low profile to the wall for a nearly seamless finish. Also available in 2-Gang, 3-Gang, and 4-Gang models. Arlington™ Arlington™ has been a leading manufacturer of quality electrical products and fittings since its founding in 1949. The company manufactures products that meet or exceed the changing needs of electrical distributors and contractors, with the vast majority produced in America.
