5 Megapixel IP Plug & Play, Outdoor Vandal Dome, 2.8mm, 98’ EXIR Range, CVBS Output, WDR, Built-in Mic, Audio Input, SD Card Slot, 12VDC/PoE

5 Megapixel IP Plug & Play, Outdoor Vandal Dome, 2.8mm, 98’ EXIR Range, CVBS Output, WDR, Built-in Mic, Audio Input, SD Card Slot, 12VDC/PoE Features 5 Megapixel (2592x1944) Resolution PAR-P5DRIR28N Fixed Lens H.265/H.264/MJPEG Compression True Day/Night 30 FPS Recording and Live True WDR 120dB IR Range up to 98’ CVBS Video Output TF Card Local Storage, 128GB Built-In Mic Audio Input IP66 Weather Resistant IK10 Vandal Resistant 12VDC/PoE Operation ONVIF Smart Analytics Free iOS & Android Apps for Smart Phones & Tablets Free Central Management Software (CMS) to manage multiple units & sites from a single platform Free MAC client software available, through the Paramont NVR, to manage your system from your Apple computer Camera PAR-P5DRIRN Image Sensor 1 / 2.5 inchCMOS Image Size 2592×1944 Electronic Shutter 1 / 25 s ~ 1 / 100000 s Iris Type Fixed Iris Min. Illumination 0.036 lux @F2.0, AGC ON; 0 lux with IR, 0.013 lux @F1.2, AGC ON; 0 lux with IR 2.8 mm @F1.85, horizontal field of view: 101°, 3.6 mm @F1.6, horizontal field of view: 79° Lens Lens Mount M12 Day & Night ICR Wide Dynamic Range 120dB BLC Yes HLC Yes Digital NR 2D / 3D DNR Angle Adjustment Pan : 0°~355°, Tilt : 0°~67°, Rotation : 0°~355° Image Video Compression H.265 / H.264 / MJPEG H.265 Compression Standard Main Profile @Leve4.1 High Tier 5MP ( 2592 × 1944 ), 4MP ( 2592 × 1520 ), 2K ( 2560 × 1440), 3MP ( 2304 × 1296 ), 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240 Resolution 60Hz : 5MP(1~30fps)/4MP(1~30fps)/ 2K(1~30fps)/3MP(1~30fps)/ 1080P(1~60fps)/ 720P(1~30fps), 50Hz : 5MP(1~25fps)/ 4MP（1~25fps）/ 2K（1~25fps）/3MP（1~25fps）/ 1080P（1~50fps）/ 720P（1~25fps） Main Stream Bit Rate 128 Kbps ~ 10 Mbps Encode Mode VBR / CBR Quality Five levels under VBR; Freely adjustable under CBR Image Settings ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser Audio Compression G711A / U ROI Each ROI to be configured separately Interfaces Network RJ45 Audio MIC IN × 1, Built-in Mic Video Output CVBS video output ( BNC × 1 ) Storage Built-in micro SD card slot; up to 128GB Functions Remote Monitoring IE browsing,CMS remote control Online Connection Support simultaneous monitoring for up to 6 users; Support multi-stream real time transmission Network Protocol TCP / IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP Interface Protocol ONVIF, GB-T/28181-2011 Storage Network remote storage; local storage Smart Alarm Motion alarm Smart Analysis Yes IR Distance 98 Feet Ingress Protection IP67 Vandal Resistant IK10 Others Power Supply DC12V/PoE Power Consumption < 9W Operating Environment - 30 °C ~ 60 °C, humidity: <95 % (non-condensing) Dimensions ( mm ) Φ 4.69 x 3.46” (Φ 119 × 87.8)
