4 Megapixel IP Network Camera Plug & Play, Outdoor Turret, 2.8mm, 65' EXIR Range, CVBS Output, PoE/DC12V
4 Megapixel IP Plug & Play, Outdoor Turret, 2.8mm, 65' EXIR Range, CVBS Output, PoE/DC12V Features 4 Megapixel (2688 x 1520) Resolution H.265/H.264/MJPEG Compression True Day/Night True WDR 120dB EXIR Range up to 65’ CVBS Video Output Audio Input IP66 Weather Resistant 12VDC/PoE Free iOS & Android Apps for Smart Phones & Tablets Free Central Management Software (CMS) to manage multiple units & sites from a single platform Free MAC client software available, through the Paramont NVR, to manage your system from your Apple computer Model: PAR-P4TXIR Image Sensor 1/3inch CMOS Image Size 2688 x 1520 Electronic Shutter 1/25s ~ 1/100000s Auto Iris Fixed Iris Min Illumination 0.05 Lux @ F1.2, AGC On; 0 Lux with IR Lens 3.6mm @ F1.6, Angle of View: 72° (Other Lens Options Available) Field of View Horizontal: 103° Vertical: 70.9° Lens Mount M12 True Day/Night ICR Wide Dynamic Range 120dB BLC Yes HLC Yes Defogging Yes Digital NR 2D/3D DNR Angle Adjustment Any Angle Video Compression H.265/H.264/MJPEG H.265 Compression Standard Main Profile @ Level 4.1 High Tier Resolution 4 MP (2592 x 1520), 2K (2560 x 1440), 3 MP (2304 x 1296), 1080p (1920x1080), 720p (1280x720), D1, CIF, 480x240 Main Stream 60Hz/30 FPS: 4MP, 2K, 3 MP, 1080p, 720p | 50Hz/25 FPS: 4MP, 2K, 3MP, 1080p, 720p Bit Rate 64Kbps ~ 10Mbps Encode Mode VBR/CBR Quality Five Levels Under VBR; Freely adjustable under CBR Image Settings ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR: Adjustable through client software or web browser Audio Compression G.711A/U ROI Each ROI to be configured separately Network RJ45 Audio MIC-in x 1 Video Output CVBS Video Output (BNC x 1) Remote Monitoring IE Browsing, CMS Remote Control Online Connection Supports simultaneous monitoring for up to 10-users; Support multi-stream real-time transmission Network Protocol TCP/IP, UDP, DHCP, UPnP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP Interface Protocol ONVIF, GB-T/28181-2011 Storage Network Remote Storage Smart Alarm Motion Alarm PoE Yes IR Distance 65 Feet Environmental IP66 Weather Resistant Power Supply DC12V/PoE Power Consumption <2.5W IR Consumption <5W Operating Environment -30° ~ 122°F (-34° ~ 50°C), 10-90% Humidity Dimensions Ø 3.42 x 4.25 Inches (87 x 108mm) Weight .94lbs (427g)
